Hpl Ct2e energy meter

SKU: SKU-892GMCSU

4.5 Product Rating

3000.00 3200.00 6% OFF

Inclusive of all taxes

Operating Voltage	240V, -40% to + 20% Phase to Neutral
Frequency Range	50 Hz +- 5%
Display	6 digit for -/5A meter and 6+1 digit for direct measurement with a digit after decimal point
Dimensions	96mm x 96mm x 86mm (L x W x H) (with connectors)
Pulse Output	Potential free contact
Pulse Duration	100m sec (Minimum)
Features	CT Operated, -/5A in class 1.0 accuracy CT Primary programmable up to 6000A (For Direct reading) No

In Stock

Quantity:

Special Offers Get the best available price on this product.

Secure Payment Safe and secure checkout experience.

Free Delivery Free shipping on eligible orders.

Product Description

Operating Voltage	240V, -40% to + 20% Phase to Neutral
Frequency Range	50 Hz +- 5%
Display	6 digit for -/5A meter and 6+1 digit for direct measurement with a digit after decimal point
Dimensions	96mm x 96mm x 86mm (L x W x H) (with connectors)
Pulse Output	Potential free contact
Pulse Duration	100m sec (Minimum)
Features	CT Operated, -/5A in class 1.0 accuracy CT Primary programmable up to 6000A (For Direct reading) No

Measures Energy accurately even under adverse supply conditions.
• LCD type display. • Low power consumption less than 1 watt per phase. Saving of more than 30% over conventional meters. • Direct reading CT operated meter. • Potential free pulse output for energy. • Finger touch-proof terminals for CT & Voltage connections. • RS 485 MODBUS available to connect up to 32 Nos. CT-2EA on one communication port over a cable distance of 1000 meters on a network. Totally 255 devices can be connected on a MODBUS network.
